Fujitsu PRIMERGY RX300 S6 - Installing a USB Drive in the 8 X 2.5 Variant; Installing a USB Drive

78 Options Guide RX300 S6
Accessible drives and LSP/LSD
7.3.2 Installing a USB drive in the 8x 2.5" variant
I In the 8x 2.5" variant, the DAT and RDX drive are installed using the
same method, except for the cabling.
7.3.2.1 Installing a USB drive
Figure 54: Removing a drive module
Ê Unlock the USB drive module by pushing the locking lever up.
Ê Push the USB drive module out frontward.
