Fujitsu PRIMERGY RX300 S6 - Installing a USB Drive

RX300 S6 Options Guide 69
Accessible drives and LSP/LSD
7.3.1.2 Installing a USB drive
Installing a USB tape drive
Figure 41: Connecting the power supply adapter cable
Ê Remove the power supply cable for the USB drive from the fan box holder.
Ê Connect the adapter cable.
Connecting the tape drive
Figure 42: Pushing the power supply and USB cable frontward through the bay
Ê Push the power supply cable frontward through the bay.
Ê Push the USB cable frontward through the bay. The black plug must be on
the outside.
