50 Options Guide RX300 S6
Processors
Figure 22: Disengaging the socket release lever
Ê Open the socket release lever (1) and swing it up as far as possible.
Ê Open the processor holder (2).
Ê Carefully lift the installed processor, that remains in vertical position, up and
out of the socket.
/
