TX200 S5 Operating Manual 23
Preface Technical data
Mechanical specifications
Weight
max. 36.8 kg (depending on configuration).
Ventilation clearance
At least 200 mm on the front and rear.
Maintenance area for the floorstand model
1.2 m
2
on the left side. Emergency access must be assured.
Ambient conditions
Condensation during operation must be avoided!
Floorstand Rack
Width (with anti-tilt bracket) 205 mm (306 mm) 486 mm
Total depth 615 mm 636 mm
Installation depth ----- 596 mm
Height 444 mm 5 HE
Environment class 3K2
Environment class 2K2
EN 60721 / IEC 721 Part 3-3
EN 60721 / IEC 721 Part 3-2
Temperature:
Operation (3K2) 10 °C .... 35 °C
Transport (2K2) -25 °C .... 60 °C
Humidity 10% .... 85%
