TX200 S5 Operating Manual 63
Installation and operation Control and display elements
5.2.1.1 ID card
You can pull out the ID card as far as it will go and push it back in again.
The ID card contains various system information, such as the product name,
serial number, order number, MAC addresses and DNS name.
5.2.1.2 Control elements
On/Off button
When the system is switched off, it can be switched on again by
pressing the On/Off button.
When the system is operating, pressing the On/Off button will
switch off the system.
I The On/Off button does not disconnect the server from the
mains voltage. To disconnect from the mains completely,
remove the power plug(s).
NMI NMI button
V CAUTION!
Do not press! Risk of loss of data! The NMI button may only
be used by service.
RST Reset button
Pressing the reset button reboots the system.
V CAUTION!
Risk of loss of data!
ID ID button
Lights up (blue) on the front and on the rear of the server when the
ID button is pressed. Both ID indicators are synchronized.
