Fujitsu PRIMERGY TX200 S5

42 Operating Manual TX200 S5
Setting up the floorstand model Installing the hardware
4.2.1 Mounting the anti-tilt bracket
I The anti-tilt bracket is only necessary for the redundant configuration
(with two hot-plug power supplies).
Figure 2: Mounting the anti-tilt bracket
Ê Place the server on the anti-tilt bracket.
Ê Fasten the anti-tilt bracket using the two knurled screws (1).
