TX200 S5 Operating Manual 61
Installation and operation Access to the drives
5.1.2 Access to the HDD modules (floorstand model)
Figure 12: Removing the hard disk cover
Ê Unlock the server (1).
Ê Remove the hard disk cover (2).
The hard disk drive cover is replaced and the server locked in the reverse order.
/
