70 Operating Manual TX200 S5
Control and display elements Installation and operation
5.2.2.2 Indicators on the hot-plug power supply unit
Figure 17: Indicators on the hot-plug power supply units
1 Indicator on hot-plug power supply unit (two colors)
Flashes green when the server is switched off, but mains voltage is
present (standby mode).
Lights up green when the server is switched on and functioning
properly.
Lights up orange if the power supply unit has failed.
/ /
