TX200 S6 Options Guide 81
Expansion cards and BBU
Figure 57: Connecting the BBU cable (example A)
Figure 58: Connecting the BBU cable (example B)
Ê Connect the BBU cable to the BBU.
V CAUTION!
Make sure that the connector side with the three dots is on the top (see
close-up). Otherwise you risk short-circuits.
