Fujitsu ScanSnap S510 User Manual

3.1 Flow of Operations
ScanSnap S510 Operator's Guide 33
Using the ScanSnap
3
2. The way that you scan the document by using a specific application (profile).
<Left-Click Menu Mode>
The following gives you detailed descriptions of a series of operations.
For the combination of ([SCAN] button) and <ScanSnap Quick Menu Mode>, see "Scanning
documents in Quick Menu Mode" on page 35.
For the combination of ([SCAN] button) and <Left-Click Menu Mode>, see "Scanning
documents in Left-Click Menu Mode" on page 40.
1) On the Left-Click Menu, select a desirable
application (profile).
2) Press the [SCAN] button to scan the
document.
⇒ The selected application starts up for you
to perform the selected action.
HINT
The Left-Click Menu Mode has the following features:
• You can scan the document at the press of a button.
• This way of scanning is suitable when you want to scan the document by using
a profile you have configured in advance.
• You can add profiles modified to suit the needs or preferences of you.

Fujitsu ScanSnap S510 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	USB 2.0
Minimum storage drive space	512 MB
Minimum system requirements	Windows 2000/ XP/ Vista
Sustainability certificates	ENERGY STAR
Power requirements	AC 100V to 240V, 50 / 60 Hz
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	2700 g
