Fujitsu STYLISTIC Q7310 - Removing the Front Camera

Page 32 of 64
Removing the front camera
Required work steps:
■ Remove keyboard
■ Remove cradle
■ Remove pen
■ Removing the LCD back cover assy
■ Remove battery
■ Remove LTE module
■ Remove the camera module
Required tools:
■ Screwdriver: Phillips, size PH00
■ Plastic tool
► Carefully release and lift the camera module in several points (yellow arrows) with a plastic tool and disconnect it from its
frame holder (green arrow).
Return to Table of Contents
Service Partner only
