Fujitsu STYLISTIC Q7310 - Remove Battery

Page 14 of 64
Remove battery
Required work steps:
■ Remove keyboard
■ Remove cradle
■ Remove pen
■ Removing the LCD back cover assy
Required tools:
■ Screwdriver: Phillips, size PH00
►
Remove the three M2XL3 screws (yellow circles).
► Remove the battery from the device (direction of the green arrows).
Return to Table of Contents
Service Partner only
