Remo
v
e CMOS batt
er
y
Required work st
eps:
■
Remove
keyboar
d
■
Remove cr
adle
■
Remove p
en
■
Removing the L
CD back co
ver assy
■
Remove bat
ter
y
Required t
ools:
■
Screwdriv
er: Phillips, size PH00
►
Disconnect the cable (yellow cir
cle).
►
Car
efully remov
e the CMOS battery (
r
ed rectangle) and the associated cable.
Please not
e!
►
It can be order
ed separately
. S
upplied t
ogether with the mainboar
d.
►
After assembling, the cable must
be returned t
o its original position (y
e
llow arro
ws).
Return t
o T
able of Contents
Ser
vice P
artner only
