► At this point, if you have not done it yet, remove the five covers (red rectangles), because they are not included in the
delivery content of the LCD module. See also chapter Remove the various covers
Please note!
Two magnets (yellow circles) are integrated in the LCD assy. These two magnets enable the STYLISTIC Q7310 to be
charged via the keyboard’s DC-in connector.
