Fujitsu Stylistic ST5000 Series User Manual

Tablet Dock Interface Port 40
53 DOCK_ON0
54 GND1
GND Ground
55 GND1
56 GND1
57 GND1
58 GND1
59 GND1
60 GND1
61 GND1
62 BAY_ID0
63 BAY_ID1
64 BAY_ID2
65 BAY_ID3
66 Reserve
67 Reserve
68 Reserve
69 GND1
GND Ground
70 GND1
71 TAB_SO
For debugging
72 PWR_TAB10
73 TAB_SI
74 TAB_SCK
75 PWR_TAB33
76 TAB_RST#
77 GND1 GND Ground
78 D_VGACLK
CRT
79 D_VGADATA
80 GND1 GND Ground
81 D_VGAVS
CRT
82 D_VGAHS
83 GND1 GND Ground
84 GND1 GND Ground for CRT
85 D_VGAB CRT
Table 4-5. Tablet Dock Interface Connector Pin Assignments
Pin Signal Name Level Description Port or Connector
