Fujitsu Stylistic ST5000 Series User Manual

Tablet Dock Interface Port 41
86 GND1 GND Ground for CRT
87 D_VGAG CRT
88 GND1 GND Ground for CRT
89 D_VGAR CRT
90 GND1 GND Ground for CRT
91 GND1 GND Ground
92 GND1 GND Ground for IEEE 1394
93 D_TPB1- IEEE 1394
94 D_TPB1+ IEEE 1394
95 GND1 GND Ground for IEEE 1394
96 D_TPA1- IEEE 1394
97 D_TPA1+ IEEE 1394
98 GND1 GND Ground for IEEE 1394
99 GND1 GND Ground
100 SAFE
Table 4-5. Tablet Dock Interface Connector Pin Assignments
Pin Signal Name Level Description Port or Connector
