V.C.I. Electrical Properties
84
Chapter 9 Reference
9-1. V.C.I. Electrical Properties
<Power Requirements>
• Rated Voltage DC 12V, 24V
• Ground Polarity (-)
• Guaranteed Operating Voltage Range DC 8.0~32.0V
• Power Supply Reverse Voltage DC -40V (1 min.)
• Stand-alone Power Consumption (Max.) 1A (Only Within Guaranteed Operating Voltage Range)
* The above values do not apply under special operating conditions, such as if an upgraded
control port or other component is short-circuited to GND, as well as under conditions outside of
the guaranteed operating voltage range.
Current consumption is 420mA or less when the unit is used at the rated power supply.
