Recording with the Drive Recorder
49
5-1-4. Group registration
(1) Group registration
Up to 5 new groups, which is the combination of
user-specified items, can be registered.
Click button after select the line (No.4 – No.8) to be
registered as group.
--- Registered group is cleared.
--- Group registration: go to section （2）へ
<Note>
• Registered contents can be corrected if you press
the button after selecting the registered item group.
• Registered item group can be used for
[Displaying the Data List Function],
[the Actuator Test Function(simultaneously displaying the
Data List)] and
[Drive recorder Function (selecting the recorded item)].
(2) Input Item Group Name
Enter up to 16 characters of group name to be registered.
--- OK: go to section （3）.
--- Cancel: go to section （1）.
<Note>
As the PC keyboard is connected, the information may be
entered either directly from the PC keyboard or from the
keyboard shown on the screen.
