Model Menu (Helicopter)
＞
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
+(/,&237(5
GOVBasic（GovernorBasicSetting）
GOVBasic（GovernorBasicSetting）
(6) Stick sw.: Stick switch
Thegovernorcanbeactivatedbythrottlestickposition.
[Settingmethod]Touchthe"StickSW"buttontoenterthesettingmode.
"Sure?"Isdisplayed.Operatethethrottlesticktothepositionwhereyou
wanttoturnGovernorON.Ifyoutouchthe[Yes]button,theONposition
ismemorized.Thisstickswitchfunctionisalwaysenabledwhenthenext
"ON/OFFsw"is"INH"orthe"GovernorON/OFFswitchisnotsetbyS.BUS
setting.
Whengovernoristurnedonandoffbytransmitterthrottlestick
 Thedataissetsothatthegovernorcanbe
turnedonandoffwiththetransmitterthrottle
stickposition.Thefollowingdescribesthis
operation.
•Throttlestickoversetpointandmorethan
60%ofsetrotationspeed.

ON
*Thisisthesettingvalueof"Gov.On.Revo:
GovernorONrevolutionsetting".
•Throttlestickheldatthesetpointormore
Remains.

ON
•Throttlestickpositionisbelowthesetpoint
selected.


OFF
Whenidleup
•Whenthethrottlecurveissetatidleup,andwhenthethrottleoutputisoverthe
setvalue(initialvalue:30%),thegovernorwillalwaysandremainONevenifthe
stickisloweredtothebottom.
(OFFatslowside)
Setpointorless
0%
100%
(Governoroperatingpoint)
Setspeed
Thestickisat,orbe
-
yondthesetpointand
is60%oftherotation
speedvalueofthe
governor.
Whenyouactivatetheswitch,thedirectionsettingoftheswitch isdis-
played.SelecttheswitchON/OFFdirection(Normal/Reverse).
Whenturningon/offgovernorwithswitch
 SelecttheON/OFFswitchchannelwith"GOVswchannel"on"SBUSBASIC"menu.
 SettingtheswitchtotheONpositionturnson,orenablesthegovernor.Thefol
-
lowingdescribesthisoperation.
•Switchsettoonpositionandenginerunningat60% or
moreofsetspeed
ON
•Throttlesticksettomaximumslowposition
ON
•Switchsettooffposition


OFF
212))VZ*RYHUQRURQRৼVZLWFK
Thisparameterallowstheusertoturnthegovernoronoroffviaaswitch
onthetransmitter.ChooseINHifyoudonotwanttouseit.
Governorcanbeturned
onandoffbyaswitch.
WhenBatteryFailSafeisenabled,itemsforsettingthethrottleservoposi-
tionaredisplayed.Thesettingmethodisthesameas"Sticksw",soplease
refertothissectionofthemanualforinformationonsettingthisfunction.
(8) BAT F/S: Battery fail safe
Whenthereceiverbatteryvoltagebecomesequaltoorlessthan"BFS.
Volt"setinthe"GOVEXPERT"menu,thebatteryfailsafefunctionisacti
-
vated,thegovernorfunctionisturnedOFF,andthethrottleservomoves
tothesetposition.
Ifthebatteryvoltageislowerthanthesetvoltageofthe"BatteryF/S"
forabout3seconds,theGx(gyro)LEDoftheCGYsolidredlight.When
"BatteryF/S"issetto"ACT"in"GOVBASIC",theservoisfixedtothe
throttlepositionsetby "BatteryF/S".When thethrottlestickissetto
theslowestposition,the"BatteryF/S"functionistemporarilycanceled.
However,after30seconds,the"BatteryF/S"functionisactivatedagain
andtheservoislocked.Whenthe"BatteryF/S"operates,quicklyland
-
ingandstoppingthehelicopter,pleasechargethebattery.
WARNING
 WhenusingtheCGYforthefirsttime,orwhenmakingchangesinthe
throwofaservoanditslinkage,alwaysperformthelimitsettingopera
-
tion.
WARNING
 WhenusingtheCGYforthefirsttime,orwhenmakingchangesinthe
throwofaservoanditslinkage,alwaysperformthelimitsettingopera
-
tion.
(9) Lim. set: Servo limit point setting
Servolimitpointsettingdefinestheoveralltravelrangeforthethrottle
servo.Itisfundamentalforgovernoroperationandmustbesetpriorto
otherfunctions.Servolimitsmustalsoberesetwhenthethrottlelinkage
ortrimarechanged.
Howtosettheservolimitpoint:
Setthetransmitter'sthrottlesticktotheidleposition.Select[Lim.SetId].
"Sure?"Isdisplayed.Ifyoutouchthe[Yes]button.  Thelimitofidlewillbe
savedtotheCGY.
Thecursorwillmoveto"Lim.SetHi".Setthesticktothe
fullhighpositionandsetthesameas"Lim.SetId".Ifthesettingdataisnot
normal(servooperationamountis50%orless),"Err"isdisplayed.In this
case,checkthetransmittersettingandrepeatthisprocedureonceagain.
(10) Limit Test: Check the set limit point
Checkthesetlimitpoint.Press"Idle"or"High"tomovetheservotoeach
limitpoint.Press“End”toendthetest.
