Model Menu (Helicopter)
＞
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
+(/,&237(5
GOVBasic（GovernorBasicSetting）
GOVBasic（GovernorBasicSetting）
7KLVPHQXVHWVWKHJRYHUQRU¶VIXQGDPHQWDOIXQFWLRQV7KHPHQX6HUYROLPLWSRLQWVHW-
WLQJPXVWEHVHW¿UVW
"
*29%$6,&
"
screen from the
"
%$6,&0(18
"
screen.
Note:Whenusingthegovernorfunction,be
suretomakeeachsettingof"GOV.BASIC".
Note:Aftercompletingthelinkageofthethrot
-
tle,besuretosetthe"Servolimitpointsetting"
first,andthensettheotherfunctions.
(1) Governor: Governor active
SetthegovernoroperationmodeofCGY.Theinitialsettingis"ACT(ac-
tive)"where,asthedesignationimplies,thegovernorisactive.Ifyoudo
notwanttousegovernor,select"INH(Inhibit)".
Setting:ACT(Active)/INH(Inhibit)Initialsetting:ACT
(2) Gear Ratio:
Inputthemainrotorgearratiobypushingthe"GearRatio"buttonto
selectthedesiredworkingmode.
Settingranges:1.00~50.00  tInitialvalue:8.00  t
Notes:
•Ifthegearratioisnotproperlyset,
thesetspeedandactualengine
speedwillbedifferent.
•Thegearratioshouldbegiveninthe
helicopterinstructionmanual.Ifthe
helicopterinstructionmanualdoes
notgivethegearratio,calculatethe
gearratioasfollows:
Rotor
main gear
N1
Engine
nion gear
N2
Gearratio=N1/N2
 Carryvalueslessthan1/1000tothe
nextwholenumber.
(3) Pole Num.: Pole number
Thisparameterisusedwhenusingadirectphasesensorattachmentto
abrushlessmotorlead.Inputthemotorpolecountasspecifiedbythe
brushlessmotormanufacturer.Whenusinganyrevolutionsensorother
thanadirectphasesensortype,setthepolenumberto2
 p.
Note:Fornitrouse,setto2
 p.
Note:TheinputsignalrangeoftheCGYis0.0
 v-3.0  v.Exceedingthisvolt-
agerangemaycausedamagetotheCGY.
Settingranges:2-24  PInitialvalue:2  P
(4) Servo Type
Selectthethrottleservotype.Digitalservosofferthebestresponse.
Setting:Analog/DG:1520Initialsetting:Analog
WARNING
 TheservotypeparameterwithintheCGYmustmatchthetypeofservo
youareusing. Incorrectsettingsmay damagetheCGYortheservo.An
incorrectsettingmayalsoresultinthelossofcontrolduringflight.
(5) RPM set.: RPM setting
SettingthemainrotorRPM.Thisiscalculatedbyenginerevolutionwith
thegearratioofthemainshaft.
Whentherotationspeedcanbesetwiththegovernormixingfunctionof
thetransmitter,itisnecessarytofirstmatchthedisplayrpmvalueof1-2-
3of"RPMSet"withthedisplayrpmvalueofthetransmitter.
Settingranges:off/700~4,000  rpmInitialvalue:1,000  rpm
*Tosetlowerthan1,000
 rpm,set"Low.Revo"of"GOV.EXPERT"menuto700  rpm.
