Function
Brake Mixing
2
(Channel setup)
The channel list screen used for brake 2 or brake 3 is displayed. Tap the auxiliary channel
that connected the servo of brake 2 or brake 3.
- When all channels are in use, a screen saying "No assignable channel" is displayed, please turn off other mixing
and make an unused channel. You can check the mixing used on the channel setting screen (page 75).
- T7PX can also be used for brake 2 or 3 by setting the steering to another auxiliary channels with the channel
setting function (P75) and making Ch.1 assignable channel (page 75).
For S-FHSS (analog)
system, 1 to 7 chan-
nels are displayed.
If there is no assignable
channel, tap [Close]. Turn
off other mixing and make
assignable channels.
To set the steering
to another auxiliary
channel and use
it for brake 2 or 3,
tap [Yes]. To cancel,
[No] is tapped.
3
(Brake 2 & 3 rate)
Tap the value button of the "Brake 2 or 3"
[Brake rate]. Value input buttons appear on
the screen, use the [+] and [-] buttons to
adjust the brake rate amount.
- When adjusting the brake amount of both brakes
after individually adjusting the Brake2 and Brake3,
select “Brake2,3 rate”.
- The brake 1 rate is linked with throttle channel (ATL)
setting.
4
(Delay amount setup)
Tap the value button of the "Brake 1 or 2,3"
[Brake delay]. Value input buttons appear
on the screen, use the [+] and [-] buttons to
adjust the delay amount.
- Since a delay at all the brakes is dangerous, a delay
is not applied to the brake to be adjusted last.
For example, when brakes 1, 2, and 3 are all used,
when a delay is applied to brakes 2 and 3, a delay
cannot be applied to brake 1. When a delay must be
applied to brake 1, the brake 2 or brake 3 delay must
be set to “0”.
Adjustment buttons
- Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Brake rate
0 ~ 100
Initial value:100
