Page 146
18) Press No until the required setting for On-Charge
Volts min (Battery) is displayed then press Yes.
The display will show:-
19) Press No until the required setting for Off-Charge
Volts max (Battery) is displayed, then press Yes.
The display will show:-
20) Press No until the required setting for Off-Charge
Volts min (Battery) is displayed, then press Yes.
The display will show:-
21) Press Yes. The display will show:-
22) Press Yes. The display will show:-
The readings given from this point on are intended as Indicator Only and should
be confirmed with a calibrated Test Meter.
23) Press No. The display will show, for example:-
24) Press Yes. The display will show, for example:-
25) Press Yes. The display will show, for example:-
The backlight will dim at this point.
26) Press Yes. The display will show, for example:-
27) Press 0 (zero). The display will show:-
28) Press No. The display will show:-
29) Press Yes. The display will show:-
PSU . . .
Diagnostics ?
PSU Test Time
= 01 Hrs
Change / List
Test Limits ?
Off - Chg. max = 14.0
Off - Chg. min = 12.6
Off - Chg. max = 14.0
Off - Chg. min > 12.6
Aux. Volts
13.6V
Battery Volts
Off Charge 12.9V
Aux. Volts
13.6V
Battery Volts
On Charge 13.6V
PSU . . .
Diagnostics ?
NovActive
Diagnostics ?
Change / List
Test Limits ?
