30) Press Yes. The display will show:-
31) Press Yes. The display will show:-
Select which battery type is installed in the
NovActive sounder. Press 6 or 8.
32) The display will show, for example:-
33) To change these limits. Press No until the required
setting for Vmax is displayed, then press Yes.
The display will show, for example:-
34) Press No until the setting required for Vmin is
displayed, then press Yes.
The display will show:-
35) To change the On-Chg limits. Press No until the required
setting for max is displayed, then press Yes.
The display will show, for example:-
36) Press No until the setting required for min is
displayed, then press Yes.
The display will show:-
37) To change the Off-Chg limits. Press No until the
required setting for max is displayed, then press
Yes.The display will show, for example:-
38) Press No until the setting required for min is
displayed, then press Yes.
The display will show:-
39) To change the Chg(mA) limits. Press No until the
required setting for max is displayed, then press
Yes. The display will show, for example:-
40) Press No until the setting required for min is
displayed, then press Yes.
The display will show:-
41) This concludes the Program Diagnostics.
Press 0 (zero) until the display shows:-
01 Jan 00: 00: 01
Set Default
Limits ?
Which Battery ?
(6)V or (8) . 4V
H / Off Vmax = 14.0
H / Off Vmax = 11.0
H / Off Vmax = 14.0
H / Off Vmax > 11.0
On - Chg. max = 7.40
On - Chg. min = 5.80
On - Chg. max = 7.40
On - Chg. min > 5.80
Off - Chg. max = 7.40
Off - Chg. min = 5.80
Off - Chg. max = 7.40
Off - Chg. min > 5.80
Chg(mA) Max = 7.40
Chg(mA). Min = 5.80
Chg(mA) Max = 7.40
Chg(mA). Min > 5.80
Change / List
Test Limits ?
