Model 560XL Section I - General
190-02313-03 Rev. 8 Textron Aviation Citation 560XL
1-11
Navigation
Specification
Operational
Requirements/
Authorization
Reference
Documents
ICAO Flight
Plan Code
Notes
Item 10a
Code
Item 18
PBN/
Advanced
RNP
See Notes for
specific
Advanced
RNP
functions.
This does not
constitute an
operational approval.
FAA AC
20-138D
CHG 2,
FAA AC
90-105A
N/A
N/A
RNAV Holding:
Supported.
RF Legs:
Supported.
Parallel Offsets: RNP-4
parallel offsets as
defined by AC 20-138D
Chapter 10 are
supported.
Advanced RNP parallel
offsets as defined by
AC20-138D Appendix 3
are supported.
Higher Continuity:
Supported when both
GIA 64E GPS/SBAS
receivers are operating
and providing GPS
navigation guidance to
their respective PFD.
Scalable RNP:
Supported through
manual CDI scaling
selection. The 0.3nm
CDI scale should be
selected whenever
RNP less than 1.0nm is
required.
Fixed Radius
Transitions (FRT):
Supported
Time of Arrival Control
(TOAC):
Not supported.
_________________________________
1. FDE/RAIM availability worldwide can be determined via the following:
•An FDE prediction tool that satisfies the guidance of FAA AC 20-138D and AC 90-105A (or
later revision), such as the Garmin WFDE prediction program, part number 006-A0154-01 or
later approved version with GPS SW >= 3.0 selected
Also, within the United States:
