Model 560XL Section II – Limitations
190-02313-03 Rev. 8 Textron Aviation Citation 560XL
FAA Approved 2-13
GRS 79 AHRS Areas of Operation Limitations (If Installed)
For aircraft equipped with the GRS 79 AHRS, flight operations with the G5000 Integrated Flight Deck are
prohibited in the following regions, due to the unsuitability of the magnetic fields near the Earth’s poles.
North of 72° North latitude, at all longitudes.
South of 70° South latitude, at all longitudes.
North of 65° North latitude, between longitude 75° W and 120° W (Northern Canada).
North of 70° North latitude, between longitude 70° W and 128° W. (Northern Canada).
North of 70° North latitude, between longitude 85° E and 114° E. (Northern Russia).
South of 55° South latitude, between longitude 120° E and 165° E (A region south of Australia
and New Zealand).
NOTE
The GARMIN G5000 installation in the Textron Model 560XL system is not
designed for use as a polar navigator. Operation outside the approved operating
area is prohibited. The GRS 79 AHRS internally monitors the magnetic field and
will display a GEO LIMITS system message when the magnetic field becomes
unsuitable for AHRS operation. When the AHRS can no longer reliably compute
heading, heading information will be removed from the HSI.
