Model 560XL Section II – Limitations
190-02313-03 Rev. 8 Textron Aviation Citation 560XL
FAA Approved 2-11
Airspeed Indicator Markings
There are no changes to airspeed limitations. Refer to the Airplane Flight Manual for airspeed
limitations.
Airspeed Indicator Markings – PFDs
Maximum Red Line
Below 8,000 feet ....................................................................................... 260 KIAS
Between 8,000 to 26,515 feet ................................................................... 305 KIAS
Above 26,515 feet ........................................................................................ 0.75 Mi
When landing gear is extended ................................................................ 250 KIAS
When flaps 7° or 15° are extended ........................................................... 200 KIAS
When flaps 35° are extended .................................................................... 175 KIAS
Green Circle Approach Speed Cue
Displayed at the computed value of 1.3 V
S
for the current configuration.
Minimum Red Line
Computed stick shaker activation speed.
