Model 560XL Section III – Operating Procedures
Abnormal Procedures
190-02313-03 Rev. 8 Textron Aviation Citation 560XL
FAA Approved 3-53
 BOTH ON ATT/HDG1, BOTH ON ATT/HDG2
BOTH ON ATT/HDG1 or BOTH ON ATT/HDG2 Annunciator displayed
This message is displayed on both PFDs and indicates that both pilot and copilot PFDs are displaying
data from the same Attitude Heading Reference System. Normally the pilot’s side displays
ATT/HDG1 information and the copilot’s side displays ATT/HDG2 information.
On the PFD displaying data from opposite AHRS:
1. PFD Softkeys: Sensors – ATT/HDG Settings – SELECT on-side ATT/HDG system (ATT/HDG1
for Pilot PFD, ATT/HDG2 for Copilot PFD)
2. PFD Displays – CONFIRM “BOTH ON ATT/HDG1” or “BOTH ON ATT/HDG2” message clears on
both PFDs.
3. If attitude and/or heading display a red “X”, reselect the functioning ATT/HDG system using the
ATT/HDG1 or ATT/HDG2 Softkey.
4. PFD Displays – CONFIRM “BOTH ON ATT/HDG1” or “BOTH ON ATT/HDG2” message is
displayed on both PFDs.
5. If an ATT/HDG system has failed, the autopilot and yaw damper will be inoperative. Perform
appropriate RVSM contingency procedures for the loss of autopilot.
Procedure completed
 BOTH ON GPS1, BOTH ON GPS2
BOTH ON GPS1 or BOTH ON GPS2 Annunciator displayed
This message is displayed on both PFDs and indicates that both pilot and copilot PFDs are displaying
data from the same GPS/SBAS receiver. Normally the pilot’s side displays GPS1 and the copilot’s
side displays GPS2. This is not pilot selectable. This may be caused by operation outside of WAAS
satellite coverage in which case the non-selected GPS is still available in the event the active GPS
fails.
1. GPS/SBAS Status – CHECK.
a. On either GTC – PUSH the Utilities button, then GPS Status.
b. Select GPS1 then GPS2 buttons and verify sufficient satellite reception.
Procedure completed
 TRANSPONDER STANDBY
FTRANSPONDER STANDBYF CAS message displayed
This CAS message indicates that the selected transponder is in standby. This message will only
display when airborne.
1. GTC Transponder Code – TOUCH.
2. Desired Transponder operating mode – TOUCH to select.
3. Verify TRANSPONDER STANDBY CAS message is no longer displayed.
Procedure completed
