Model 560XL Section II – Limitations
190-02313-03 Rev. 8 Textron Aviation Citation 560XL
FAA Approved 2-7
Oil Pressure Indicators
Model Excel (Aircraft Serial Numbers 560 – 5001 through 560 – 5500)
* See AFM for transient time limitations
NOTE 1: If the engine oil pressure is > 140 PSI but ≤ 250 PSI prior to engine start
(< 45% N
2
), the high oil pressure condition will be considered a start
condition, and the color change to red on the numeric display of oil
pressure will be suppressed for up to 300 seconds.
Oil Pressure (PSI) N
2
Numeric Oil
Pressure
Display Color
> 0 and < 20 Any
White text on red
background
≥ 20 and < 45
≤ 60%
Green text on black
background
> 60%
Black text on amber
background
≥ 45 and ≤ 140 Any
Green text on black
background
> 140 and ≤ 250
Within transient time limit *
Any
Black text on amber
background
NOTE 1
> 140 and ≤ 250
Exceeding transient time limit *
Any
White text on red
background
> 250 Any
White text on red
background
To Next Page
