CHAPTER 2: Checking Out Your Notebook
6
Front
Component Icon Description
Power indicator
•
LED on - Notebook is on.
•
LED blinking - Notebook is in Sleep or
Hybrid Sleep mode.
•
LED off - Notebook is off.
Battery charge
indicator
•
LED orange - Battery is fully charged.
•
LED blinking orange - Battery is
charging.
•
LED blinking red - Battery charge is very
low.
•
LED solid red - Battery is
malfunctioning.
Important: This LED only lights up when
your notebook is connected to AC power
or the battery charge is very low.
Headphone jack Plug amplified speakers or headphones
into this jack. The built-in speakers are
turned off when speakers or headphones
are plugged into this jack.
•
Headphone 1 with SPDIF support
•
Headphone 2
Microphone
jack
Plug a microphone into this jack.
Speakers Provide audio output when headphones
or amplified speakers are not plugged in.
Headphone jack 1
Microphone jack
Battery charge indicator
Power
indicator
Speaker
Headphone jack 2
To Next Page
