CHAPTER 2: Checking Out Your Notebook
12
Keyboard area
Keyboard area for select models
Memory
bay
Memory modules are located in this bay.
Ventilation
fan
Helps cool internal components.
Warning: Do not work with the notebook
resting on your lap. If the air vents are blocked,
the notebook may become hot enough to harm
your skin.
Caution: Do not block or insert objects into
these slots. If these slots are blocked, your
notebook may overheat resulting in
unexpected shutdown or permanent damage
to the notebook.
Caution: Provide adequate space around your
notebook so air vents are not obstructed. Do
not use the notebook on a bed, sofa, rug, or
other similar surface.
Component Icon Description
Status indicators
Power
button
Multimedia
touch
controls
(optional)
Touchpad
Multimedia
panel
(optional)
Keyboard
Status
indicators
Microphones
