Instructions for SL500DCL/SL800DCL
www.gatexpertstore.com
Additional remote controls: Spare/Additional remotes for the automatic gate kit, these will need to
be paired to the motor.
Infrared photocell: Detects pedestrians, vehicles and objects that cross an infrared beam and
prevents the gate from closing.
Wireless keypad: Allows secure access through the gate used with a user set code.
Wired control: Allow users to control the opening and closing of the gate through an external
push-button.
Alarm lamp: Alerts people near the gate and users that the gate is in operation.
Technical Parameters
Single button mode / Three button mode
Recording of up Remote Controls
Installation
Before You Start
· SL500DCL/SL800DCL Sliding Gate Automation Kit is suitable for powering the opening and
closing motion of gates up to 500, 800kg in weight, up to a length of 12m. (Standard kit
contains a 6m chain, if the gate length is over 5.5m, please consider to extend the length of the
chain.)
· Gate motion is achieved by the rotating output gear of the gate opener driving the gear rack
(sold separately) fitted to the moving gate.
· The gate opener requires you to press the remote control once to open, and once again to
close. This is a safety feature to ensure safe operation.
· The opener must be fitted within private property, never externally to a property’s boundary.
Any works done to the gate opener must be completed whilst the power is off and the opener is
unplugged. Any modifications/alterations/works to AC power components must only be completed by
a licensed electrician
