GATEXPERT SL500DCL - Programming and Wiring

Instructions for SL500DCL/SL800DCL
www.gatexpertstore.com
14
X7 Terminal
X2 Terminal
Set Button
Indicator Light
X5 Terminal
Hall Line
Programming and Wiring
Any works to the 110V/220V AC must only be performed by a licensed electrician.
Ensure power is off before any modifications are made.
Figure 19
X4 Terminal
Motor Terminal
X6 Terminal
