Instructions for SL500DCL/SL800DCL
www.gatexpertstore.com
Tools Required
· Tape measure
· Level
· 12mm concrete drill and hammer (when uses expansion screws)
· Phillips head screwdriver
· Straight screwdriver
Example Sliding Gate
Gate Track and Track Wheels Gate End Catch Gate Guide Rollers Gate Stop
Figure 4
Please ensure that the gate opener power cable is not plugged in at any stage before Step 8.
Step 1 - Gate Preparation
· Ensure that the sliding gate is correctly installed.
· The gate is horizontal and level and the gate can glide back and forth smoothly when moved by
hand before installing the gate opener.
· Wheels and guide rollers should rotate easily and be free from dirt or grime.
· Track should be flat, level and firmly affixed.
· Any misalignment in the gate will affect performance of the automatic gate opener.
The gate should slide smoothly by hand before attempting to install the gate opener.
Figure 5
