GATEXPERT SL500DCL - Three-button Mode Learning

Instructions for SL500DCL/SL800DCL
www.gatexpertstore.com
23
B. Operation Graphic Illustration
Three-button Mode Learning (L2)
Under this mode, all buttons on the remote control which are paired to the gate opener will
be separately used for gate opening
、
closing and stop. (Please refer to Figure 26 for the
usage for the forth button on the remote control)
Figure 25
A. Operation Instruction
Open
Close
Stop
Pedestrian Mode
Press “-” for 2 sec.
L1 will be steady on
Press “SET” once
Press the button to
be paired twice
L1-L5 will be on in
sequence, then flicker
once and off
Save and exit
SET
L1-L5 will flicker
repeatedly
