8.3 Rotary Attachment Option
The rotary attachment option provides the E200 with the ability to engrave on cylindrical or spherical
objects. In addition to the standard X, Y, Z axis, the rotary attachment allows for a fourth axis which
rotates your object 360° to allow for engraving on cups, wine glasses, and even spherical objects.
Work Piece Limitations
Maximum Length
250 mm (10 inches)
Maximum Loading Weight
3kg (6 lbs.)
Min. Diameter (upper axle center)
5mm (0.2 inches)
Max. Diameter (upper axle center)
50mm ( 2inches)
Min. Diameter (lower axle center)
50mm (2 inches)
Max. Diameter (lower axle center)
70mm (3 inches)
 GCC design two axle-center for E200 rotary attachment to enlarge the availability object
sizes.
