Maintenance instructions
6.4 QS4 Technical Reference Manual
LCD Indication Event Type Definition
Card 0x, Mapping In Progress Monitor Indicates Signature devices are in the process of
being mapped.
Card 0x Unconfig. Device Trouble Indicates that a new signature device has been
detected on a loop.
Card 0x, Line Initialization Monitor
Occurs after power up or a restart. Indicates
signature devices are being initialized.
Card 0x, Loop Ground Fault Trouble Indicates a ground fault on a signature module.
Card 0x, LIM Driver Fault Trouble Internal hardware failure.
Card 0x, RAM Supervision Trouble Internal memory fault
Card 0x, ROM Supervision Trouble Internal memory fault
Card 0x, EEPROM Supervision Trouble Internal memory fault
Table 6-5: Dialer pseudo points
LCD Indication Event Type Definition
Primary Phone Line:check Telco Trouble Telephone line has low or no voltage
Secondary Phone Line:check Telco Trouble Telephone line has low or no voltage
Pri. Receiver Failed to answer Trouble Dialer attempted to dial event to CMS but did not
get an answer.
Sec. Receiver Failed to answer Trouble
Dialer attempted to dial event to CMS but did not
get an answer.
Dialer Account 1 Fault Trouble Indicates dialer did not get proper handshake for
event sent to the CMS for Account 1.
Dialer Account 2 Fault Trouble
Indicates dialer did not get proper handshake for
event sent to the CMS for Account 2.
Dialer Account 3 Fault Trouble Indicates dialer did not get proper handshake for
event sent to the CMS for Account 3.
Dialer Account 4 Fault Trouble
Indicates dialer did not get proper handshake for
event sent to the CMS for Account 4.
Dialer Account 5 Fault Trouble Indicates dialer did not get proper handshake for
event sent to the CMS for Account 5.
Dialer Account 6 Fault Trouble
Indicates dialer did not get proper handshake for
event sent to the CMS for Account 6.
Dialer Account 7 Fault Trouble Indicates dialer did not get proper handshake for
event sent to the CMS for Account 7.
Dialer Account 8 Fault Trouble Indicates dialer did not get proper handshake for
event sent to the CMS for Account 8.
Dialer ROM Fault Trouble Internal memory fault
Dialer Queue Overflow Trouble Indicates that too many dialer messages are trying
to be sent.
Dialer Card, RAM Supervision Trouble Internal memory fault
