GE 239

4-18 239 Motor Protection Relay GE Multilin
4 PROGRAMMING 4 PROGRAMMING
4
MESSAGE ▼
MESSAGE ▲
| RTD 1
|
RTD 1 APPLICATION:
STATOR
RTD 1 TYPE:
100 PT
RTD 1 TRIP
TEMPERATURE
≥ 130 °C
| RTD 2
|
Range: STATOR, BEARING, OFF
Range: 100PT, 100NI, 120NI, 10CU
Range: 0 to 200°C, OFF; step 1°C
0 to 400°F, OFF; step 1°F
RTD 2 APPLICATION:
STATOR
| RTD 3
|
RTD 1 ALARM
TEMPERATURE
≥ 110 °C
RTD 2 TYPE:
100 PT
RTD 2 TRIP
TEMPERATURE
≥ 90 °C
RTD 3 APPLICATION:
BEARING
RTD 3 TYPE:
100 PT
RTD 3 TRIP
TEMPERATURE
≥ 90 °C
SEE NEXT PAGESEE NEXT PAGE
MESSAGE ▲
MESSAGE ▲
MESSAGE ▼
MESSAGE ▼
RTD 3 ALARM
TEMPERATURE
≥ 75 °C
SEE PREVIOUS PAGESEE PREVIOUS PAGE
| RTD SENSOR FAILURE
|
RTD SENSOR FAILURE
ALARM: OFF
MESSAGE ▲
MESSAGE ▼
Range: 0 to 200°C, OFF; step 1°C
0 to 400°F, OFF; step 1°F
RTD 2 ALARM
TEMPERATURE
≥ 75 °C
Range: STATOR, BEARING, OFF
Range: 100PT, 100NI, 120NI, 10CU
Range: 0 to 200°C, OFF; step 1°C
0 to 400°F, OFF; step 1°F
Range: 0 to 200°C, OFF; step 1°C
0 to 400°F, OFF; step 1°F
Range: ON, OFF
Range: STATOR, BEARING, OFF
Range: 100PT, 100NI, 120NI, 10CU
Range: 0 to 200°C, OFF; step 1°C
0 to 400°F, OFF; step 1°F
Range: 0 to 200°C, OFF; step 1°C
0 to 400°F, OFF; step 1°F
DESIGNATES SETPOINTS
THAT ARE ONLY VISIBLE IF
RTD OPTION IS INSTALLED
