GE 735

GE Power Management 735/737 Feeder Protection Relay 2-
5
2 INSTALLATION 2.2 ELECTRICAL
2
2.2 ELECTRICAL 2.2.1 WIRING
Different connection schemes are possible depending on the application. Typical connections are shown on the following
page where the 735/737 is used as primary protection. Ensure that the wiring diagram number on the drawout chassis label
matches the number of the instruction manual wiring diagram. Terminals are numbered in rows. Use the labels on the back
of the relay to identify terminals with a row letter and position number. Terminal numbers and symbols on the back of the
relay should match the wiring diagram in this manual.
