735/737 Feeder Protection Relay 1-5
1 INTRODUCTION 1.2 ORDERING
1
1.2 ORDERING 1.2.1 ORDER CODES
The CT secondary must be specified with an order as 1 or 5 amps. The RS485 communications interface is available with
RS422 as an option. For 19" rack mount applications, single and dual cutout panels for mounting one or two relays are
available. These are 3 units high (10.5") for 19-inch rack mounting, made of 14 gauge steel and come in ASA 61 gray. See
Section 2.1.1: MOUNTING on page 2–1 for dimensions of the relay and panels. For bench testing, the 735/737 can be
ordered mounted in a portable case.
The GE Power Management order code is as follows:
1.2.2 ACCESSORIES
The following additional accessories are available:
• 19-1 PANEL: Single cutout panel
• 19-2 PANEL: Dual cutout panel
• SCI: RS232 to RS485 convertor
• 3" Collar: SR series collar 1009-0055
• 1 " Collar: SR series collar 1009-0047
• Optional Mounting Kit: 1819-0030
1.2.3 REVISION HISTORY
Table 1–1: ORDER CODES
735
737
–
–
S
S
–
–
S
S
–
–
S
S
–
–
S
S
Basic Unit 735
737
|
|
|
|
|
|
|
|
Standard 735 Relay with 50/51, 50G/51G protection
737 Relay (same as 735 with 8 additional output relays)
Phase CT
Secondary
1|| |
1 A Phase CT secondaries
5|| |
5 A Phase CT secondaries
Ground CT
Secondary
1 | |
1 A Ground CT secondaries
5 | |
5 A Ground CT secondaries
Control Power LO |
20 to 60 V DC; 20 to 48 V AC at 50/60 Hz
HI |
90 to 300 V DC; 70 to 265 V AC at 50/60 Hz
Options 485
RS485 2-wire communications (standard)
422
RS422 4-wire communications (optional)
DEMO
735 Demo/Test case
3
8
---
MANUAL P/N FIRMWARE REVISION RELEASE DATE
1601-0048-D1 735.D1 11/12/1992
1601-0048-D2 735.D1.2 12/08/1992
1601-0048-D3 735.D1.2 01/12/1993
1601-0048-D4 25D130D1.000 03/03/1993
1601-0048-D5 25D131D1.000 03/10/1993
1601-0048-D6 25D140D1.000 04/28/1993
1601-0048-D7 25D141D1.000 09/28/1993
1601-0048-D8 25D150D1.000 03/21/1994
1601-0048-D9 25D151D1.000 06/10/1994
1601-0048-DA 25D152D1.000 06/06/1995
1601-0048-DB 25D152D1.000 12/07/2000
1601-0048-DC 25D152D1.000 02/15/2001
1601-0048-DD 25D153D1.000 04/18/2001
1601-0048-DE 25D154D1.000 08/13/2001
