735/737 Feeder Protection Relay 6-7
6 TESTING 6.2 TEST RECORDS
6
6.2.10 GROUND FAULT OVERCURRENT CURVE VERIFICATION
6.2.11 POWER FAIL/RECOVER TEST
6.2.12 HI POTENTIAL TEST
Note the Filter Ground (terminal G11) must be left floating for this test. See Section 2.2.7 HI-POT TESTING on page 2–12
for details.
PICKUP
LEVEL
CURVE SHAPE TIME
MULT
TIME
SHIFT
INPUT
CURRENT ( )
EXPECTED
TIME
MEASURED
TIME
STATUS
POWER FAIL/RECOVERY LEVEL (V) MEASURED LEVEL (V) STATUS
FAIL @
RECOVER @
HIPOT LEVEL (kV) DURATION ( ) STATUS
