[20] Freeze output
[21] Speed up
[22] Speed down
[23] Set-up select bit 0
[24] Set-up select bit 1
[30] Counter input
[32] Pulse input
[34] Ramp bit 0
[36] Line failure inverse
[37] Fire Mode
[52] Run permissive
[53] Hand start
[54] Auto start
[55] DigiPot increase
[56] DigiPot decrease
[57] DigiPot clear
[60] Counter A (up)
[61] Counter A (down)
[62] Reset Counter A
[63] Counter B (up)
[64] Counter B (down)
[65] Reset Counter B
[66] Sleep Mode
[78] Reset Maint. Word
[120] Lead Pump Start
[121] Lead Pump Alternation
[130] Pump 1 Interlock
[131] Pump 2 Interlock
[132] Pump 3 Interlock
E-24 Function Relay
Array [8]
(Relay 1 [0], Relay 2 [1]
Option OPCRLY: Relay 7 [6], Relay 8 [7] and Relay 9 [8])
Option: Function:
[0] * No operation Select options to define the function of the relays.
The selection of each mechanical relay is realised in an array parameter.
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Standby / no warning
[5] Running
[6] Running / no warning
[8] Run on ref/no warn
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
