Par. No. # Parameter description Default value 4-set-up Change during opera-
tion
Conver-
sion index
Type
PB-0#
PB-00 Setpoint 0 N/A All set-ups TRUE 0 Uint16
PB-07 Actual Value 0 N/A All set-ups FALSE 0 Uint16
PB-1#
PB-15 PCD Write Configuration ExpressionLimit 2 set-ups TRUE - Uint16
PB-16 PCD Read Configuration ExpressionLimit 2 set-ups TRUE - Uint16
PB-18 Node Address 126 N/A 1 set-up TRUE 0 Uint8
PB-2#
PB-22 Telegram Selection [108] PPO 8 1 set-up TRUE - Uint8
PB-23 Parameters for Signals 0 All set-ups TRUE - Uint16
PB-27 Parameter Edit [1] Enabled 2 set-ups FALSE - Uint16
PB-28 Process Control [1] Enable cyclic master 2 set-ups FALSE - Uint8
PB-4#
PB-44 Fault Message Counter 0 N/A All set-ups TRUE 0 Uint16
PB-45 Fault Code 0 N/A All set-ups TRUE 0 Uint16
PB-47 Fault Number 0 N/A All set-ups TRUE 0 Uint16
PB-5#
PB-52 Fault Situation Counter 0 N/A All set-ups TRUE 0 Uint16
PB-53 Profibus Warning Word 0 N/A All set-ups TRUE 0 V2
PB-6#
PB-63 Actual Baud Rate [255] No baudrate found All set-ups TRUE - Uint8
PB-64 Device Identification 0 N/A All set-ups TRUE 0 Uint16
PB-65 Profile Number 0 N/A All set-ups TRUE 0 OctStr[2]
PB-67 Control Word 1 0 N/A All set-ups TRUE 0 V2
PB-68 Status Word 1 0 N/A All set-ups TRUE 0 V2
PB-7#
PB-71 Profibus Save Data Values [0] Off All set-ups TRUE - Uint8
PB-72 ProfibusDriveReset [0] No action 1 set-up FALSE - Uint8
PB-8#
PB-80 Defined Parameters (1) 0 N/A All set-ups FALSE 0 Uint16
PB-81 Defined Parameters (2) 0 N/A All set-ups FALSE 0 Uint16
PB-82 Defined Parameters (3) 0 N/A All set-ups FALSE 0 Uint16
PB-83 Defined Parameters (4) 0 N/A All set-ups FALSE 0 Uint16
PB-84 Defined Parameters (5) 0 N/A All set-ups FALSE 0 Uint16
PB-9#
PB-90 Changed Parameters (1) 0 N/A All set-ups FALSE 0 Uint16
PB-91 Changed Parameters (2) 0 N/A All set-ups FALSE 0 Uint16
PB-92 Changed Parameters (3) 0 N/A All set-ups FALSE 0 Uint16
PB-93 Changed Parameters (4) 0 N/A All set-ups FALSE 0 Uint16
PB-94 Changed Parameters (5) 0 N/A All set-ups FALSE 0 Uint16
7.2.12 PB-## Profibus
AF-600 FP High Power Operating Instructions
134
