Par. No. # Parameter description Default value 4-set-up Change during opera-
tion
Conver-
sion index
Type
DN-0# DN-00 DeviceNet Protocol null 2 set-ups FALSE - Uint8 DN-01 Baud Rate Select null 2 set-ups TRUE - Uint8
DN-02 MAC ID ExpressionLimit 2 set-ups TRUE 0 Uint8
DN-05 Readout Transmit Error Counter 0 N/A All set-ups TRUE 0 Uint8
DN-06 Readout Receive Error Counter 0 N/A All set-ups TRUE 0 Uint8
DN-07 Readout Bus Off Counter 0 N/A All set-ups TRUE 0 Uint8
DN-1#
DN-10 Process Data Type Selection null All set-ups TRUE - Uint8 DN-11 Process Data Config Write ExpressionLimit 2 set-ups TRUE - Uint16 DN-12 Process Data Config Read ExpressionLimit 2 set-ups TRUE - Uint16
DN-13 Warning Parameter 0 N/A All set-ups TRUE 0 Uint16
DN-14 Net Reference [0] Off 2 set-ups TRUE - Uint8
DN-15 Net Control [0] Off 2 set-ups TRUE - Uint8
DN-2# DN-20 COS Filter 1 0 N/A All set-ups FALSE 0 Uint16 DN-21 COS Filter 2 0 N/A All set-ups FALSE 0 Uint16
DN-22 COS Filter 3 0 N/A All set-ups FALSE 0 Uint16
DN-23 COS Filter 4 0 N/A All set-ups FALSE 0 Uint16
DN-3#
DN-30 Array Index 0 N/A 2 set-ups TRUE 0 Uint8 DN-31 Store Data Values [0] Off All set-ups TRUE - Uint8 DN-32 Devicenet Revision ExpressionLimit All set-ups TRUE 0 Uint16
DN-33 Store Always [0] Off 1 set-up TRUE - Uint8
DN-34 DeviceNet Product Code 210 N/A 1 set-up TRUE 0 Uint16
DN-39 Devicenet F Parameters 0 N/A All set-ups TRUE 0 Uint32
DN-5#
7.2.11 DN-## DevicNet
