Par. No. # Parameter description Default value 4-set-up Change during opera-
tion
Conver-
sion index
Type
O-0# O-01 Control Site null All set-ups TRUE - Uint8 O-02 Control Word Source null All set-ups TRUE - Uint8
O-03 Control Word Timeout Time ExpressionLimit 1 set-up TRUE -1 Uint32
O-04 Control Word Timeout Function [0] Off 1 set-up TRUE - Uint8
O-05 End-of-Timeout Function [1] Resume set-up 1 set-up TRUE - Uint8
O-06 Reset Control Word Timeout [0] Do not reset All set-ups TRUE - Uint8
O-07 Diagnosis Trigger [0] Disable 2 set-ups TRUE - Uint8
O-1# O-10 Control Word Profile [0] Drive Profile All set-ups TRUE - Uint8 O-13 Configurable Status Word STW [1] Profile Default All set-ups TRUE - Uint8
O-3#
O-30 Protocol null 1 set-up TRUE - Uint8 O-31 Address ExpressionLimit 1 set-up TRUE 0 Uint8 O-32 Drive Port Baud Rate null 1 set-up TRUE - Uint8
O-33 Drive Port Parity null 1 set-up TRUE - Uint8
O-35 Minimum Response Delay ExpressionLimit 1 set-up TRUE -3 Uint16
O-36 Maximum Response Delay ExpressionLimit 1 set-up TRUE -3 Uint16
O-37 Maximum Inter-Char Delay ExpressionLimit 1 set-up TRUE -5 Uint16
O-4#
O-40 Telegram Selection [1] Standard telegram 1 2 set-ups TRUE - Uint8 O-5# O-50 Coasting Select [3] Logic OR All set-ups TRUE - Uint8 O-52 DC Brake Select [3] Logic OR All set-ups TRUE - Uint8 O-53 Start Select [3] Logic OR All set-ups TRUE - Uint8
O-54 Reversing Select null All set-ups TRUE - Uint8
O-55 Set-up Select [3] Logic OR All set-ups TRUE - Uint8
O-56 Preset Reference Select [3] Logic OR All set-ups TRUE - Uint8
O-8# O-80 Bus Message Count 0 N/A All set-ups TRUE 0 Uint32 O-81 Bus Error Count 0 N/A All set-ups TRUE 0 Uint32
O-82 Slave Messages Rcvd 0 N/A All set-ups TRUE 0 Uint32
O-83 Slave Error Count 0 N/A All set-ups TRUE 0 Uint32
O-89 Diagnostics Count 0 N/A 1 set-up TRUE 0 Int32
O-9# O-90 Bus Jog 1 Speed 100 RPM All set-ups TRUE 67 Uint16 O-91 Bus Jog 2 Speed 200 RPM All set-ups TRUE 67 Uint16
O-94 Bus Feedback 1 0 N/A 1 set-up TRUE 0 N2
O-95 Bus Feedback 2 0 N/A 1 set-up TRUE 0 N2
O-96 Bus Feedback 3 0 N/A 1 set-up TRUE 0 N2
7.2.9 O-## Options/Comms
