AN-50 Terminal 42 Output
Option: Function:
Select the function of Terminal 42 as an analog current output.
[0] * No operation
[100] Output frequency 0 - 100 Hz
[101] Reference Minimum reference - Maximum reference
[102] Feedback -200% to +200% of par. 20-14
[103] Motor Current : 0 - Inverter Max. Current (par. DR-37 Drive Max. Current)
[104] Torque rel to limit : 0 - Torque limit (par. F-40 Torque Limiter (Driving))
[105] Torq relate to rated : 0 - Motor rated torque
[106] Power 0 - Motor rated power
[107] Speed 0 - Speed High Limit (par. F-17 Motor Speed High Limit [RPM] and par. F-15 Motor Speed High Limit [Hz])
[113] Ext. Closed Loop 1 0 - 100%
[114] Ext. Closed Loop 2 0 - 100%
[115] Ext. Closed Loop 3 0 - 100%
[130] Output freq. 4-20mA 0 - 100 Hz
[131] Reference 4-20mA Minimum Reference - Maximum Reference
[132] Feedback 4-20mA -200% to +200% of par. 2-14
[133] Motor cur. 4-20mA 0 - Inverter Max. Current (par. DR-37 Drive Max. Current)
[134] Torq.% lim 4-20 mA :0 - Torque limit (par. F-40 Torque Limiter (Driving))
[135] Torq.% nom 4-20mA 0 - Motor rated torque
[136] Power 4-20mA 0 - Motor rated power
[137] Speed 4-20mA 0 - Speed High Limit (par. 4-13 and par. 4-14)
[139] Bus ctrl. 0 - 100%
[140] Bus ctrl. 4-20 mA 0 - 100%
[141] Bus ctrl t.o. 0 - 100%
[142] Bus ctrl t.o. 4-20mA 0 - 100%
[143] Ext. CL 1 4-20mA 0 - 100%
[144] Ext. CL 2 4-20mA 0 - 100%
[145] Ext. CL 3 4-20mA 0 - 100%
NB!
Values for setting the Minimum Reference is found in open loop par. F-52 Minimum Reference and for closed loop par. CL-13 Minimum Reference/Feedb. - values
for maximum reference for open loop is found in par. F-53 Maximum Reference and for closed loop par. CL-14 Maximum Reference/Feedb..
AN-51 Terminal 42 Output Min Scale
Range: Function:
0.00 %* [0.00 - 200.00 %] Scale for the minimum output (0 or 4 mA) of the analogue signal at terminal 42.
Set the value to be the percentage of the full range of the variable selected in par. AN-50 Terminal 42
Output.
