GE af-600 fp

Illustration 3.1: Compact IP 21 (NEMA 1) and IP 54 (NEMA 12), Unit Size 41
Illustration 3.2: Compact IP 21 (NEMA 1) and IP 54 (NEMA 12) Unit Size 42
1) AUX Relay 5) Brake
01 02 03 -R +R
04 05 06 81 82
2) Temp Switch 6) SMPS Fuse (see fuse tables for part number)
106 104 105 7) AUX Fan
3) Line 100 101 102 103
R S T L1 L2 L1 L2
91 92 93 8) Fan Fuse (see fuse tables for part number)
L1 L2 L3 9) Mains ground
4) Load sharing 10) Motor
-DC +DC U V W
88 89 96 97 98
T1 T2 T3
AF-600 FP High Power Operating Instructions
13
3
