Illustration 3.3: Compact IP 00 (Chassis), Unit Size 43
Illustration 3.5: Position of earth terminals IP00 (Chassis), 4X unit sizes
Illustration 3.6: Position of earth terminals IP21 (NEMA type 1) and IP54
(NEMA type 12)Unit Size 42
NB!
Unit sizes 42 and 44 are shown in above examples. Unit sizes 41 and 43 are equivalent.
AF-600 FP High Power Operating Instructions
14
3
