GE af-600 fp

Par. No. # Parameter description Default value 4-set-up Change during opera-
tion
Conver-
sion index
Type
DR-7# DR-70 Pulse Output #29 [Hz] 0 N/A All set-ups FALSE 0 Int32 DR-71 Relay Output [bin] 0 N/A All set-ups FALSE 0 Int16
DR-72 Counter A 0 N/A All set-ups TRUE 0 Int32
DR-73 Counter B 0 N/A All set-ups TRUE 0 Int32
DR-75 Analog In X30/11 0.000 N/A All set-ups FALSE -3 Int32
DR-76 Analog In X30/12 0.000 N/A All set-ups FALSE -3 Int32
DR-77 Analog Out X30/8 [mA] 0.000 N/A All set-ups FALSE -3 Int16
DR-8# DR-80 Fieldbus CTW 1 0 N/A All set-ups FALSE 0 V2 DR-82 Fieldbus REF 1 0 N/A All set-ups FALSE 0 N2
DR-84 Comm. Option STW 0 N/A All set-ups FALSE 0 V2
DR-85 Drive Port CTW 1 0 N/A All set-ups FALSE 0 V2
DR-86 Drive Port REF 1 0 N/A All set-ups FALSE 0 N2
DR-9# DR-90 Alarm Word 0 N/A All set-ups FALSE 0 Uint32 DR-91 Alarm Word 2 0 N/A All set-ups FALSE 0 Uint32
DR-92 Warning Word 0 N/A All set-ups FALSE 0 Uint32
DR-93 Warning Word 2 0 N/A All set-ups FALSE 0 Uint32
DR-94 Ext. Status Word 0 N/A All set-ups FALSE 0 Uint32
DR-95 Ext. Status Word 2 0 N/A All set-ups FALSE 0 Uint32
DR-96 Maintenance Word 0 N/A All set-ups FALSE 0 Uint32
AF-600 FP High Power Operating Instructions
139
7
