No. Description Warning Alarm/Trip Alarm/Trip Lock Parameter Reference
1 10 Volts low X
2 Live zero error (X) (X) par. AN-01
3 No motor (X) par. H-80
4 Mains phase loss (X) (X) (X) par. SP-12
5 DC link voltage high X
6 DC link voltage low X
7 DC over voltage X X
8 DC under voltage X X
9 Inverter overloaded X X
10 Motor Elec. OL over temperature (X) (X) par. F-10
11 Motor thermistor over temperature (X) (X) par. F-10
12 Torque limit X X
13 Over Current X X X
14 Earth fault X X X
15 Hardware mismatch X X
16 Short Circuit X X
17 Control word timeout (X) (X) par. O-04
23 Internal Fan Fault X
24 External Fan Fault X par. SP-53
29 Heatsink overtemp X X X
30 Motor phase U missing (X) (X) (X) par. E-78
31 Motor phase V missing (X) (X) (X) par. E-78
32 Motor phase W missing (X) (X) (X) par. E-78
33 Inrush fault X X
34 Fieldbus communication fault X X
36 Mains failure X X
38 Internal fault X X
39 Heatsink sensor X X
40 Overload of Digital Output Terminal 27 (X) par. E-00, E-51
41 Overload of Digital Output Terminal 29 (X) par. E-00, E-51
42 Overload of Digital Output On X30/6 (OPCGPIO) (X) par. E-56
42 Overload of Digital Output On X30/7 (OPCGPIO) (X) par. E-57
46 Pwr. card supply X X
47 24 V supply low X X X
48 1.8 V supply low X X
49 Speed limit X
50 Auto Tune calibration failed X
51 Auto Tune check U
nom
and I
nom
X
52 Auto Tune low I
nom
X
53 Auto Tune motor too big X
54 Auto Tune motor too small X
55 Auto Tune parameter out of range X
56 Auto Tune interrupted by user X
57 Auto Tune timeout X
58 Auto Tune internal fault X X
59 Current limit X
61 Tracking Error (X) (X) par. H-20
62 Output Frequency at Maximum Limit X
64 Voltage Limit X
65 Control Board Over-temperature X X X
66 Heat sink Temperature Low X
67 Option Configuration has Changed X
68 Safe Stop Activated
X
1)
69 Pwr. Card Temp X X
70 Illegal Drive configuration X
72 Dangerous Failure
X
1)
73 Safe Stop Auto Restart
77 Reduced power mode X
79 Illegal PS config X X
80 Drive Restored to Factory Settings X
85 Profibus/Profisafe Error
91 Analog input 54 wrong settings X
92 NoFlow X X par. AP-2#
93 Dry Pump X X par. AP-2#
94 End of Curve X X par. AP-5#
95 Broken Belt X X par. AP-6#
96 Start Delayed X par. AP-7#
97 Stop Delayed X par. AP-7#
98 Clock Fault X par. K-7#
Table 9.2: Alarm/Warning code list
