4.1 Site requirements
S
ystem dimensions
Property Value
Width × Depth × Height (approximate
±
10 mm)
1295 × 1215 × 1920 mm
System dry weight (approximate) 715 kg
Space requirements
Make sure to have enough free space on the sides and in front of the system when it
has been installed to allow for service and maintenance.
At least 100 mm free space is needed on the back of the system (where the cabinet
door is located) for ventilation.
Ambient environment
The following conditions should be avoided:
• Sources of heat, such as direct sunlight
• Strong magnetic or electric fields
• Vibrations
• Corrosive gas
• Dust
• Temperatures outside recommended operating ranges, see Section 9.1 Specifica-
tions, on page 150.
Compressed air
• Dry and particle free air
• Airflow 50 NL/min
• Supply pressure 6.5 to 10 bar g
Electrical power
Refer to General specifications, on page 150 for power, voltage and phase require-
ments.
4 Installation
4
.1 Site requirements
ÄKTA ready XL Operating Instructions 29281616 AE 77
*** TeDIS Valid on Date Printed Printed on: 15-09-2023 11:27:35 ***
